The lightest-weight Softail equipped with a Milwaukee-Eight 114 engine for a quick and nimble ride with power to spare. A perfect performance base for customization with 2-up seating, black steel laced wheels and dark finishes deliver no nonsense, Raw Bobber attitude.
*Financing Offer available only on new Harley-Davidson® motorcycles financed through Eaglemark Savings Bank and is subject to credit approval. Not all applicants will qualify as the Annual Percentage Rate (APR) will vary based on the applicant’s past credit performance and the term of the loan. A financing offer is available only for up to a 60-month term. For example, a 2023 Fat Boy® 114 motorcycle in Vivid Black with an MSRP of $20,199, no down payment and amount financed of $20,199, 60-month repayment term, and 3.99% APR results in monthly payments of $371.90. In this example, the customer is responsible for applicable taxes, title, licensing fees and any other fees or charges at the time of sale. APR is calculated according to the simple interest method. Not valid in conjunction with other offers. Customers must take delivery by September 30, 2023. Other terms, conditions, and limitations may apply. Dealer participation may vary. Financing offer is subject to change or cancellation at any time. See a White’s Family of Dealership Sales Associate for details.
Length: | 91.3 in |
Seat height, laden: | 25.8 in |
Seat height, unladen: | 26.8 in |
Ground clearance: | 4.9 in |
Rake (steering head): | 30 |
Trail: | 6.2 in |
Wheelbase: | 64.2 in |
Tires, front specifications: | 100/90B19,57H,BW |
Tires, rear specifications: | 150/80B16,77H,BW |
Fuel Capacity: | 3.5 gal |
Oil capacity: | 5 qt. |
Weight, as shipped: | 631 lbs |
Weight, in running order: | 655 lb |
Engine: | Milwaukee-Eight® 114 |
Bore: | 4.0 in |
Stroke: | 4.5 in |
Displacement: | 113.99 in3 |
Compression ratio: | 10.5:1 |
Fuel system: | Electronic Sequential Port Fuel Injection (ESPFI) |
Exhaust: | 2-into-2 offset shotgun; catalyst in muffler |
Primary drive: | Chain, 34/46 ratio |
Gear ratios (overall) 1st: | 9.311 |
Gear ratios (overall) 2nd: | 6.454 |
Gear ratios (overall) 3rd: | 4.793 |
Gear ratios (overall) 4th: | 3.882 |
Gear ratios (overall) 5th: | 3.307 |
Gear Ratios (overall) 6th: | 2.79 |
Engine torque testing method: | EC 134/2014 |
Engine torque: | 118.7 ft-lb |
Engine torque (RPM): | 3000 |
Lean angle, right (deg.): | 28.5 |
Lean angle, left (deg.): | 28.5 |
Fuel economy testing method: | EU 134/2014 |
Fuel economy: | 0.00 mpg |
CO2 emissions testing method: | EU 134/2014 |
CO2 emissions : | 128 g/km CO2 |
Wheels, front type: | Black, Annihilator cast aluminum |
Wheels, rear type: | Black, Annihilator cast aluminum |
Brakes, caliper type: | 4-piston fixed front and 2-piston floating rear |
Lights (as per country regulation), indicator: | High beam, turn signals, neutral, low oil pressure, engine diagnostics, ABS (if equipped), security, low battery voltage, low fuel |
Gauges: | 2.14 inch viewable area LCD display with speedometer, gear, odometer, fuel level, clock, trip, range and tachometer indication |
